Campbelltown railway station

Campbelltown railway station
Details
Station Code	CTN
TfNSW Stop Number	256020
Suburb	Campbelltown
Number of Platforms	4
Platform Config.	1 side, 1 island, 1 dock
Services
Lines served

Leumeah Campbelltown Macarthur

Southern Highlands Line
Macarthur Campbelltown railway station Glenfield

Mittagong Campbelltown Central

Campbelltown railway station, is on the T8 Airport and South Line of the Sydney Trains network, as well as the northern terminus for the Southern Highlands Line of the NSW TrainLink intercity network. It serves the suburb of Campbelltown, including the local area and shopping precinct. Station entry is accessed from Hurley Street and Farrow Road, with a bus interchange also located at the eastern side of the station. Located east of the station is Campbelltown City Council and Campbelltown Mall shopping centre.

Campbelltown is staffed 24 hours everyday.[1]

History

Campbelltown station opened on 17 May 1858. Between 1882 and 1963 it was the junction station for the Campbelltown-Camden line.

On 5 May 1968, the Main South line was electrified from Liverpool. It was the extremity of the Sydney suburban network until it was extended. A new station to the south, Macarthur opened in July 1985. However many services still terminate at Campbelltown.

In 2009, as part of the Transport Access Program, Campbelltown station received a car park extension, which added 380 new car spaces. The upgrade spanned from July to December.[2]

In January 2013, the Southern Sydney Freight Line opened on the western side of the station. The station is surrounded by an extensive network of sidings to stable terminating Sydney Trains rolling stock.

Since the second half of 2017, Campbelltown railway station has been served exclusively by the Airport and East Hills line, meaning commuters have to change at Glenfield to travel to either the city via Granville or to Blacktown/Schofields via the Cumberland Line.

Platforms and Services

Platform	Line	Stopping Pattern	Notes
		Terminating services, returning to the City Circle via Sydenham (pm peak only), Services to City Circle Via Sydenham (am peak only)
		Services to the City Circle via Airport
		Peak hour services to Central
		Services to Central (set down only)
		Services to Macarthur
		Services to Moss Vale and Goulburn (peak only)
		Services to Canberra, Griffith and Melbourne (pick up only)
		Terminating services, returning to Moss Vale and Goulburn
		Terminating services, returning to Canberra, Griffith and Melbourne

Campbelltown has 4 platforms. Platform 1 is a refuge road, usually used for terminating trains. Platforms 2 and 3 serve the mainline tracks in the up and down directions respectively. Platform 4 is four car long dock platform, usually used for terminating Southern Highlands services.

There is a series of points around the station to allow trains to move in and out of Campbelltown Yard from the north. Trains can terminate from the north on platforms 1-3, but usually use platform 1 so that the mainline is not blocked. Trains can terminate from the south on platforms 1-4, but can only return to the south from platforms 2-4. There is no crossover from the up line to platform 4, so trains use the previous crossover at Macarthur and run on the down line in both directions between Macarthur and Campbelltown.

Map

Loading map...

{"type":"ROADMAP","minzoom":false,"maxzoom":false,"types":["ROADMAP","SATELLITE","HYBRID","TERRAIN"],"mappingservice":"googlemaps3","width":"auto","height":"350px","centre":false,"title":"","label":"","icon":"","lines":[],"polygons":[],"circles":[],"rectangles":[],"copycoords":false,"static":false,"visitedicon":"","wmsoverlay":false,"zoom":14,"layers":[],"controls":["pan","zoom","type","scale","streetview","rotate"],"zoomstyle":"DEFAULT","typestyle":"DEFAULT","autoinfowindows":false,"resizable":false,"kmlrezoom":false,"poi":true,"cluster":false,"clustergridsize":60,"clustermaxzoom":20,"clusterzoomonclick":true,"clusteraveragecenter":true,"clusterminsize":2,"imageoverlays":[],"kml":[],"gkml":[],"searchmarkers":"","fullscreen":false,"scrollwheelzoom":false,"locations":[{"text":"","title":"","link":"","lat":-34.0643789,"lon":150.8139626,"icon":""}]}

Transport links

Campbelltown Bus Interchange is split in two sections. Stands A to F are located on Hurley Street and stands G and H are located on Farrow Road.

Campbelltown Bus Interchange

Stand	Routes	Notes
A: Transit Systems	890: to Harrington Park or Narellan 891: to Mount Annan South 895: to Camden 896: to Oran Park
B: Transit Systems	880: to Kearns 885A: to Bradbury 887: to Wollongong via Appin Road 889: to Spaniards Main
D: Transit Systems	Arrivals only
E: Transit Systems	878: Campbelltown Loop Service 879: to Leumeah 880: to Minto
F: Transit Systems	881: to Leumeah North 882: to Leumeah South 883: to Ruse 883K: to Kentlyn via Ruse
G: Transit Systems	878: to Campbelltown Hospital
H: Transit Systems	840: to Oran Park Town Centre 880: to Kearns or Minto

T8 Airport and South Line

City Circle Town Hall, Wynyard, Circular Quay, St James, Museum, Central Airport Line City Circle ← Green Square, Mascot, Domestic, International, Wolli Creek East Hills Line Airport Line ← Turrella, Bardwell Park, Bexley North, Kingsgrove, Beverly Hills, Narwee, Riverwood, Padstow, Revesby, Panania, East Hills, Holsworthy Main South Line East Hills Line ← Glenfield, Macquarie Fields, Ingleburn, Minto, Leumeah, Campbelltown, Macarthur Terminus → Illawarra Junction (peak only) Redfern, St Peters, Sydenham East Hills Line → Fleet B set (Waratah Series 2) - A set (Waratah) - M set (Millennium) - K set Line details - Sydney Trains

Southern Highlands Line
↑ Terminus, Central, Glenfield, Campbelltown, Macarthur, Menangle Park, Menangle, Douglas Park, Picton, Tahmoor, Bargo, Yerrinbool, Mittagong, Bowral, Burradoo, Moss Vale, Exeter, Bundanoon, Penrose, Wingello, Tallong, Marulan, Goulburn Terminus ↓ Fleet N set (Endeavour Railcar) Line details - NSW TrainLink

NSW TrainLink Regional Southern Line

Sydney Metropolitan ↑ Terminus, Central, Campbelltown, Main South Line (Southern Highlands) Mittagong, Bowral, Moss Vale, Bundanoon, Goulburn, Bombala Branch line (to ACT) Tarago, Bungendore, Queanbeyan, Canberra, Terminus ← Main South Line (Gunning to Junee) Gunning, Yass Junction, Harden, Cootamundra, Junee, Yanco-Griffith rail-line Coolamon, Narrandera, Leeton, Griffith, Terminus ← Main South Line (Wagga Wagga to Culcairn) Wagga Wagga, The Rock, Henty, Culcairn, Victoria Albury, Wangaratta, Benalla, Seymour, Broadmeadows, Southern Cross, Terminus ↓
